1 Panel color: iron black and silver panel
2 Power input conditions (single-phase 3-wire): AC220-240V (AC90-240V optional) 50-60HZ two-phase (three-wire: zero, fire, ground)
3 channel quantity: 8-way universal socket relay controlled and 2-way universal socket direct output
4 Relay controlled output maximum tolerable single power/total power (reactive power): 2000W/6000W maximum tolerable reactive power
5 Output power socket specifications: flame-retardant ABS material, phosphor copper material that can withstand up to 13A current, standard universal socket
6 Features:
1. Turn on in sequence and turn off in reverse.
2. PASS key can open all channels at the same time
3. Accurate voltage display
4. With 32A air switch
7 Interval time/timing time of each switch: 1.5 seconds
8 Output relay contact current: 30A 277VAC
9 Circuit board specifications: double-sided fiberboard, the main power line is thickened and thickened twice
10 Power supply specifications: built-in transformer voltage AC220-240V, optional (switching power supply is suitable for global voltage AC90-260V) 50-60HZ
11 Specification of main cable: 3*4 square cable, total length of 1 meter (with power input plug)
12 Open type: square rocker switch
13 Function display voltage meter type: red digital tube display voltage meter
14 Body size: length 480MM * width 165MM * height 48MM (non-standard 1U) , Total weight (including packaging): 3KG
15 Stand-alone packaging size: length 510MM * width 260MM * height 10MM (color printing box)
16 Packing way: 1 piece per color box; 5pcs per carton, total 16KG, carton size: length 562MM * width 274MM * height 450MM
